| Bộ vi xử lý |
Support for 7th and 6th generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/Intel® Core™ i3 processors/ Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package L3 cache varies with CPU |
| Chipset |
Intel® Z270 Express Chipset |
| Khe cắm mở rộng |
1 x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x16 slot, running at x8 (PCIEX8) * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode. 1 x PCI Express x16 slot, running at x4 (PCIEX4) * The PCIEX4 slot shares bandwidth with the M2P_32G connector. The PCIEX4 slot operates at up to x2 mode when an SSD is installed in the M2P_32G connector. 3 x PCI Express x1 slots * The PCIEX1_3 slot shares bandwidth with the SATA3 1 connector. The SATA3 1 connector becomes unavailable when the PCIEX1_3 is populated. (All of the PCI Express slots conform to PCI Express 3.0 standard.) |
| Cổng I/O ở trong |
1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x U.2 connector 2 x M.2 Socket 3 connectors 3 x SATA Express connectors 6 x SATA 6Gb/s connectors 1 x CPU fan header 1 x water cooling CPU fan header 4 x system fan headers 2 x system fan/water cooling pump headers 1 x front panel header 1 x front panel audio header 2 x USB 3.1 Gen 1 headers 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header 1 x RGB (RGBW) LED strip extension cable header 1 x Thunderbolt™ add-in card connector 1 x Clear CMOS jumper 2 x temperature sensor headers 1 x power button 1 x reset button 1 x Clear CMOS button 1 x ECO button 1 x OC button 1 x audio gain control switch Voltage Measurement Points 2 x BIOS switches |
| Cổng I/O phía sau |
1 x PS/2 keyboard/mouse port 1 x DisplayPort 1 x HDMI port 1 x Thunderbolt™3 port (USB Type-C™ port, with USB 3.1 Gen 2 support) 1 x USB 3.1 Gen 2 Type-A port (red) 5 x USB 3.1 Gen 1 ports 2 x RJ-45 ports 1 x optical S/PDIF Out connector 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In/Mic In, Line Out, Headphone) |
| Lan |
1 x Intel® GbE LAN chip (10/100/1000 Mbit)(LAN1) 1 x Killer E2500 LAN chip (10/100/1000 Mbit) (LAN2) |
| Âm thanh |
Creative® Sound Core 3D chip Support for Sound Blaster Recon3Di TI Burr Brown® OPA2134 operational amplifier High Definition Audio 2/5.1-channel Support for S/PDIF Out |
| Giao tiếp |
Chipset+Intel® Thunderbolt™ 3 Controller: 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel Chipset+Realtek® USB 3.1 Gen 1 Hub: 4 x USB 3.1 Gen 1 ports (available through the internal USB headers) Chipset: 5 x USB 3.1 Gen 1 ports on the back panel 4 x USB 2.0/1.1 ports (available through the internal USB headers) |
| Bộ nhớ |
4 x DDR4 DIMM sockets supporting up to 64 GB of system memory |
| Kích thước |
ATX Form Factor; 30.5cm x 24.4cm |
| Hãng sản xuất |
Gigabyte |
