PERFORMANCE

Display Size

23.8"

View Area

527x296.5 mm

Panel

In-Plane Switching

Backlight

WLED

Aspect Ratio

16:9

Resolution

1920x1080

Pixel Pitch

0.2745x0.2745 mm

Dot / Pixel Per Inch

92 dpi

View Angle (H / V)

178° / 178°

Response Time

4ms GtG (Extreme mode) / 6ms GtG (Typical mode)

Color Support

16.7 Million

Refresh Rate

100Hz

Brightness

250 cd/m²

Contrast Ratio

1300:1

Color Gamut

99% sRGB

Screen Surface Treatment

Anti-glare

Curvature

Flat Panel

Camera

None

Microphone

None

Speakers

2Wx2

Power Consumption (Typical / Maximum)

13W / 24W

Power Adapter

Integrated

Touchscreen

None

Smart System

None

DESIGN

Stand

Tilt, Swivel, Pivot, Height Adjust Stand

Case Color

Raven Black

Side Bezel Width

2.0 mm

Mounting

Supports VESA mount 100 x 100 mm

ThinkCentre M Series Support

Tiny Support

Pen

None

Dimensions (WxDxH)

• Lowest Position | 539.8 x 178.6 x 343.4 mm (21.25 x 7.03 x 13.52 inches)
• Highest Position | 539.8 x 178.6 x 498.4 mm (21.25 x 7.03 x 19.62 inches)
• Head Only | 539.8 x 44.0 x 325.7 mm (21.25 x 1.73 x 12.82 inches)

Packaging Dimensions (WxDxH)

710.0 x 111.0 x 421.0 mm (27.95 x 4.37 x 16.57 inches)

Weight

• Monitor With Stand | 4.5 kg (9.9 lbs)
• Monitor Head Only | 2.9 kg (6.4 lbs)

Packaging Weight

6.4 kg (14.1 lbs)

CONNECTIVITY

USB Port

None

Video Connector

1x HDMI® 1.4, 1x DP 1.2, 1x VGA

Network Connectivity

None

SERVICE

Base Warranty

3-year

CERTIFICATIONS

Environmental Certification

ENERGY STAR® Certified, TCO 10, TCO Edge 2.1, EPEAT™ Gold, RoHS, EU Energy Efficiency Level (Level-C)

Ergonomic Certification

TÜV Low Blue Light (Hardware solution), TÜV Rheinland® Flicker Free

Sync Technology

None

Special Features

Natural Low Blue Light

SOFTWARE

Operating System

Support Windows® 10, Windows 11

ACCESSORIES

Video Cables

HDMI® cable

MODEL INFORMATION

Model

64BAMAR1VN

Machine Type

64BA

Region

ASN

EAN / UPC / JAN

0198156755414 / 198156755414 / None

Announce Date

2025-06-09
