Sequential Read Speed**

Up to 520 MB/s

Sequential Write Speed**

Up to 210 MB/s

Random Read Speed***

Up to 70,000

Random Write Speed***

Up to 50,000

Capacity

128GB

Controller

Marvell 88SS9188

NAND Flash

TOSHIBA A19nm Toggle MLC

DRAM Cache

256MB DDR3

Form Factor

M.2 2242

Interface

M.2 SATA 6Gb/s

Power Connector

M.2 connector for DC 3.3V input

Data Connector

M.2 connector

Dimension (L x W x H)

42 x 22 x 3.65 mm / 1.65 x 0.87 x 0.14 inch

Weight

6g / 0.21oz (Max.)

Power Consumption

0.25W (MobileMark) / 0.2mW (DEVSLP)

DC Requirement

3.3V / 0.95A

Temperature

0°C ~ 70°C / 32°F ~ 158°F (Operating)

Shock

1500G (Max.), at 1 msec half-sine

Vibration

7 ~ 800Hz, 2.17Grms (Operation)

MTBF

> 1,500,000 hours

Warranty

3-Year

Operating System Supported

Microsoft Windows OS / Linux OS

Agency Approval

UL, CE, BSMI, WHQL, RoHS, VCCI, KCC, FCC, RCM

Command Set Support

TRIM, S.M.A.R.T., NCQ, ATA/ATAPI-8

DATA Encryption

AES 256

Firmware Upgrade

Supported

Features

TrueSpeed, TrueProtect, DEVSLP mode
